Unidirectional perspective glass
Low light one-way lens (atomic mirror) / One-way glass , also known as one-way mirror, is a kind of visible light has a high reflectance glass, under the weak light environment, can be observed clearly has a strong light source environment. The reflector of the one-way mirror must be the meeting light side or toward the outside.
One-way glass is a special need. The effect we want to achieve is that the observer wants to observe the observed person, and the person who wants to be observed cannot be aware that he is observed. Therefore, we need one-way perspective products.
|
Product Name |
One-way mirror (two-way mirror) |
|
|
Glass type |
Tempered glass |
|
|
Maximum size |
2440*3660mm |
|
|
Deep processing type |
Ordinary laminated, hollow, explosion-proof, bulletproof |
|
|
Thickness |
Single Panel |
4mm, 6mm, 8mm, 10mm, 12mm |
|
Laminaed |
4+4mm, 6+6mm, 8+8mm, 10+10mm, 12+12mm, ect. |
|
|
Hollow |
5+9A+5mm, 5+12A+5mm, 6+9A+6mm, 6+12A+6mm, ect. |
|
|
Explosion-proof |
5mm+1.14PVB+polymer material+1.14PVB+5mm |
|
|
Bullet-proof |
8+8+8mm, 10+10+10mm, 6+12+6mm, ect. |
|
|
Maximum size |
1830*2440mm |
|
|
Jacket color |
Silver white, silver gray |
|
|
Edge Standard |
Edge, polished edge |
|
|
Shape |
Any shape can be customized |
|
|
Type |
Back |
Front |
|
Thickness |
6 mm |
6 mm |
|
Color |
Silver gray |
Silver gray |
|
Transmittance |
9% |
72% |
|
Light reflectivity |
87% |
10% |
|
Absorb |
21% |
21% |
|
Heat transfer coefficient |
4.1 |
4.1 |
|
Shading coefficient |
0.31 |
0.31 |
|
U value |
10.9 |
10.9 |
|
K value |
6.19 |
6.19 |
